Bitmap2LCD supports the following Dot Matrix formats
[ Width x Height ]
96x40,100x32,112x64,120x32,122x32,128x32,128x64,
128x128,144x32,160x80,160x128,192x32,192x64,
192x128,240x64,240x128.
A user defined dot matrix size option is implemented !
(up to 240 x128)
Note : For heights above 128 pixels ( up to 240 ), a canvas zooming function is implemented in the STANDARD edition.
Find more information on the online FORUM
At the right side, a picture of a LED backlighted 128 x 64 graphic LCD module.
The original color GIF smiley found on the internet was converted to gray scale, then filtered to black and white using the balance trackbar slider.
